View into fourth floor stairwell
Fair face concrete walls with steel balustrade
Detail of handrail
The handrail features 'bumps' to the underside, to assist with those visually impaired
The Theatre downstairs
The detailing of the leather clad seating was used as a reference in the design of seating booths
Bar area at first floor level
The bar benefits from a full width balcony overlooking Sloane Square
View into stair well
To the top of the image, the mezzanine bar area
Internal servicing
Pipes and conduits are fixed simply to the soffit
Back of house
Pulley systems related to the stage handling
The grid
Back of house system, to raise and lower sets
Internal stairwell
Insitu cast stair flights with steel balustrade
Detail of wash hand basin
A common detailing to back of house dressing room areas
Detail of window opening mechanism
Operates back of house window shutters
